Ultimate Manual for Hickok 533 Tube Tester, US $19.95 – Picture 0
Ultimate Manual for Hickok 533 Tube Tester, US $19.95 – Picture 0

Ultimate Manual For Hickok 533 Tube Tester

US $19.95

  • Orange Park, Florida, United States
  • Jan 29th
Open on mobile:
QR code
 The Hickok 533 and 533A are different. I also have the 533A manual listed on Ebay. This is a very nice comb-bound laser reprint of the owners manual for the Hickok 533 tube tester. All of my manuals are scanned on a high end 11x17" scanner, cleaned up in Paint.net, and printed on a business class laser printer. There is a color cover, protected with a clear sheet. The first section is the complete Operating Instructions. There is a list of Ballast Tubes and data for testing them, and a list of Sub-Miniature tubes and test data for them. There is a parts list and a nice big 11x17" fold-out schematic diagram. Detailed calibration instructions are included. There are 15 pages in this section. The second section is the roll chart of testing data in book form. It is chart number 3200-44, dated 11-1-1961. There are 22 pages in this section. Additional useful info I have added:  Next are three pages of American to Foreign and Foreign to American charts. Next is an amazing 4 page section where he actually created correct test data for tubes that Hickok never provided data for. Next is a 2 page section of test data for electron ray (Eye) tubes that shows how to give them a more complete test than the regular chart does. Both of these sections he created were done for the 800A, so the switch positions are correct but for some tubes the bias settings may vary a bit on the 600A. The way to perfect them for the 600A is to test some new tubes and adjust the bias until you get the proper meter reading. The next section (9 pages) is a very good Foreign to American number chart. The next section (10 pages) crosses over those 4 digit military numbers to their regular equivalents and the reverse. The last section (10 pages) is a collection of Foreign to American cross over charts. First class postage is $3.50 in the USA. Foreign bidders are welcome, but please do not ask me to falsify customs documents. You may also use PayPal.com (preferred) for faster service. Please see my Ebay store for lots of great manuals. Posted with the eBay Android app
