Vacuum Table Vt4040gal Cnc Chuck Engraving Or Milling

US $691.00

Exeter, Rhode Island, United States
Jan 30th

Open on mobile:
QR code

Vacuum Tables, Vacuum Table, Vacuum Clamps, Vacuum Pods and T-tracks from Clampusystems.com Vacuum Table VT4040GAL for CNC, Milling (15.75” x 15.75” vacuum area) Hole Grid -Vacuum Table Maximum precision with high grade, precision aluminum Check out our Videos at: www.ClampuSystems.com/Videos.html Buying tools is a matter of trust! This vacuum table is a true industrial grade tool made 100% from aluminum. Its 27 mm high grade, cast, precision aluminum machined on both sides guarantees accuracy and enormous vibration damping. The included images illustrate the high performance of these vacuum clamping tables Also Included in this sale! T-sliding blocks or the mounting base are used to fasten the unit in place. The table should be operated in conjunction with a vacuum pump, which ideally should have a pump capacity of 25m?/h (15 CFM). Depending on application, a pump volume of 10m?/h (6 CFM) with a minimum of 25” of Hg. is sufficient when completely covered. The retaining force is proportional to covered area, the coefficient of friction, and the pressure differential. A perforated rubber mat is included with each vacuum table shipment to increase the coefficient of friction and protect the table. This also makes it possible to mill work pieces through. Perforated rubber mats are therefore wear parts and can be reordered from us at a low cost at any time. Here is an example of the results achieved by vacuum milling techniques when used properly. This test uses a vacuum table 4220 RAL, available in our shop, to lift a mesh box filled with wood and an approximate weight of 500 kg., which is over half a ton. Here is the corresponding video below The use of cooling lubricants when milling metals is not a problem for these systems. However, with greater volumes, you must ensure to connect a fluid separator between table and pump to keep the pump from being damaged. We also sell liquid separators. The table should be aligned and trued after assembly to achieve the highest degree of precision and accuracy. Make sure the table is a bit smaller than the machine’s traverse path in order to be able to true the table all the way to the edge. >>Video<< Included in delivery: n Vacuum table VT4040GAL n 1 Holed Rubber Mat Holed Mat n 1 Solid Rubber Mat (to Cover unused holes) n Valve/Gauge Manifold and hose Material: All Solid Aluminum Overall dimensions: 16.57 x 16.22 inch (421 x 412 mm) Vacuum Area: 15.75 x 15.75 inch (400 x 400 mm) Height: 1.06 inch (27 mm) Ports: (4) Quick connect hose ports Note: This type vacuum table is designed to work with a pump, venturi or blower, not a shop vac. This type table is not suitable for clamping wood products. We do have tables that will clamp wood type products. We carry a wide variety of vacuum tables and are constantly engaged in further development and new technological solutions. Not all of our vacuum systems are suitable for marketing on Ebay, therefore if you don’t see it on Ebay, we may have it in stock or can create custom orders. Just ask us!! Phone: 401-385-3181 Fax: 401-753-6331 >>Video<<
