Wavecrest Binary Tree Digital Switching Matrix Dsm-16 16 Ports 110-230vac B6

US $575

Hayward, California, United States
May 28th

Open on mobile:
QR code

Wavecrest BInary Tree Digital Switching Matrix DSM-16 110-230 VAC 16 Ports Used. It powers on and we can see the light on all switches, no further testing was done. The DSM-16 is a binary tree matrix with over 3 GHz bandwidth and two groups of 8 inputs, significantly extending the input capacity of the WAVECREST DTS series of Digital Time Systems The DSM-16 is a binary tree matrix with over 3 GHz bandwidth and two groups of 8 inputs, significantly extending the input capacity of the WAVECREST DTS series of Digital Time Systems. Its advanced design allows signals to pass through with minimal degradation and distortion, maintaining a low noise, high accuracy environment. The slimline, rack-mountable DSM-16 may be controlled manually from the front panel or remotely via the RS232C port on the back of the DTS system. Remote control of the DSM-16 via GPIB commands to the DTS makes integration into an automated environment fast, without any special hardware or software. Performance Specifications Frequency Range DC - 3 GHz @ 3db VSWR 1.25 : 1 Max Insertion Loss 1.1 dB Max Isolation 100 dB Min Skew to any path ± 10 ps Max Impedance 50 Ohms nominal Unused inputs Terminated 50 Ohms to ground Matrix switching time < 50="" ms=""> Relay Control RS232C from DTS 2070C Front panel inputs + 1.3 VAC maximum Front panel inputs + 1.3 VAC maximum Minimum relay life 5 million switches per channel (Maximum input voltage must not exceed + 1.3 VAC) Voltage requirements 90 to 260 VAC @ 50 - 60 Hz *** What you see is what you get! Pictures are taken at the time of listing. If it's not in the photos, it's not included in the lot, unless otherwise stated directly in the ad. *** Available for local pick up at our office in Hayward, California Shipping quoted includes any handling charges plus UPS Ground (5-7 days), Insured, to the lower 48 States only. If you need it shipped elsewhere, please contact us for a shipping quote. Depending on your location, your shipping may be less, in which case we will refund the difference. Returns are accepted within 30 days. Re-stocking fees may apply. Please see our full return policy for details. If you have questions or concerns, please message us, or call Nancy or Isidro at 510-784-1111. We're here Monday-Friday, 8 am - 4:30 pm PST, and at other times by chance! ! ~ Thank You For Shopping ~ ! 07803 C27-S3-B2 IR 11-B6
