Pts 310 Frequency Syntheziser 1-310 Mhz, 310r1n1x-49/x-54

US $355.00

Gilroy, California, United States
Jan 29th

Open on mobile:
QR code

PTS 310 FREQUENCY SYNTHESIZER 0.1 MHz to 310 MHz new standard in performance/price, with choice of spurious suppression DDS standard with phase-continuous switching flexible phase rotation options +3 to +13 dBm output 1 Hz resolution fully programmable BCD or GPIB, with remote-only versions available space-saving 3 1/2" cabinet rack mount ears included SPECIFICATIONS Frequency Range: 0.100 000 MHz to 309.999 999 MHz Resolution: 1 Hz Accuracy: same as frequency standard Control: manual by 10-position dial; remote by TTL-level parallel entry BCD or GPIB (optional) Switching Time (to within 0.1 radian at new frequency) 100 MHz - 10 MHz digit: 20 µseconds 1 MHz digit: 5 µseconds 100 KHz - 1 Hz digit: < 1 µsecond transient, 2 µsecond delay, phase-continuous Output Level: +3 to +13 dBm (1V max, 50 ? ) Flatness: ± 0.5 dB Impedence: 50 ? Control: manual by front panel control; remote by analog voltage Spurious (at full power output, + 13 dBm) Outputs Type 1 Type 2 Discrete: -65 dBc -60 dBc Harmonics: -30 dBc -30 dBc Phase Noise: -68 dBc -63 dBc (0.5 Hz to 15 KHz) including the effects of internal standard ? (1Hz): 100 Hz/ -105 dBc, 1 KHz/ -115 dBc, 10 KHz/-123 dBc, 100 KHz/ -127 dBc Noise Floor: -135 dBc/Hz Optional Phase Rotation: 0°, 90°, 180°, 270° in 90° steps 0-360° in .225° steps Frequency Internal: OCXO or TCXO Standard 3x10-9/day 1x10-8/day ± 1x10-8/0-50° C ± 1x10-6/0-50° C 1x10-6/year 2x10-6/year External Drive: 10 MHz, 0.4 Vrms into 50 ? ; 5 MHz, 0.5 Vrms into 50 ? Aux. Output: 10.000 MHz, 0.4 Vrms into 50 ? (Note: internal or external standard required for operation) General Operating Ambient: 0-55° C, 95% R.H. Power: 105 - 125V, 50 - 400 Hz, 40W (100, 220, 240V optional) Dimensions: 19 x 3.5 x 17.5 inches (relay rack or bench cabinet) Weight: 20 lbs. Pricing (USA domestic) $6,465 (Type 1) or $5,830 (Type 2) plus any other options Includes Power cord (US)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Prgrammable Test Sources
Country/Region of Manufacture	United States
Model	310R1N1X-49/X-54
